Cam iQ Configuration Guide
This article identifies the correct installation configuration code (SKU) for a Cam iQ device based on five setup parameters: camera count, audio setting, Journey Snapshot setting, DMS setting, and In Cab Warning setting. Use this article to answer questions like "What config do I need for a [camera count] camera with [audio setting], [journey snapshot setting]?" All resulting codes follow the pattern WD-XXX-A16V09-[description].
Cam iQ Flowchart
Configuration Parameters
- Device Type: Cam iQ (this guide only covers Cam iQ; other device types are out of scope)
- Camera Count: Single or Dual
- Audio: On or Off
- Journey Snapshot: On or Off
- DMS (Driver Monitoring System): On or Off — this question only applies to Dual camera configurations. Single camera configurations skip this step entirely.
- In Cab Warning: On or Off — this question only applies when DMS is On. If DMS is Off, In Cab Warning does not apply and is skipped.
- Confirm the device type is Cam iQ.
- Determine Camera Count: Single or Dual.
- If Single: determine Audio (On/Off), then Journey Snapshot (On/Off). This fully determines the result — no DMS or In Cab Warning question applies to Single camera setups.
- If Dual: determine Audio (On/Off), then Journey Snapshot (On/Off), then DMS (On/Off).
- If DMS is Off, the result is determined immediately — no In Cab Warning question applies.
- If DMS is On, also determine In Cab Warning (On/Off) to reach the final result.
- Some Dual-camera combinations with DMS On and In Cab Warning On are Not Available — there is no valid configuration code for that combination.
Single Camera
| Audio | Journey Snapshot | Result |
|---|---|---|
| Off | On | WD-919-A16V09-Single-Audio-Off-snapshot |
| Off | Off | WD-916-A16V09-Single-Audio-Off |
| On | On | WD-920-A16V09-Single-Audio-On-snapshot |
| On | Off | WD-917-A16V09-Single-Audio-On |
Dual Camera
| Audio | Journey Snapshot | DMS | In Cab Warning | Result |
|---|---|---|---|---|
| Off | On | On | On | WD-929-A16V09-Dual-Audio-Off-DMS-WARN-snap |
| Off | On | On | Off | WD-913-A16V09-Dual-Audio-Off-DMS-NOWARN-snap |
| Off | On | Off | N/A | WD-918-A16V09-Dual-Audio-Off-snapshot |
| Off | Off | On | On | Not Available |
| Off | Off | On | Off | WD-912-A16V09-Dual-Audio-Off-DMS-NOWARN |
| Off | Off | Off | N/A | WD-915-A16V09-Dual-Audio-Off |
| On | On | On | On | Not Available |
| On | On | On | Off | Configuration code not yet assigned — escalate to the configuration team to confirm the SKU for Dual / Audio On / Journey Snapshot On / DMS On / In Cab Warning Off. |
| On | On | Off | N/A | WD-927-A16V09-Dual-Audio-On-snapshot |
| On | Off | On | On | Not Available |
| On | Off | On | Off | WD-923-A16V09-Dual-Audio-On-DMS-NOWARN |
| On | Off | Off | N/A | WD-914-A16V09-Dual-Audio-On |
One valid-looking combination — Dual camera, Audio On, Journey Snapshot On, DMS On, In Cab Warning Off — has no SKU recorded in the source flowchart. Do not guess a code for this combination; confirm with the configuration team and update this article once resolved.
Example Questions and AnswersQ: I have a dual cam, audio needs to be on, journey snapshot off and DMS off. What config do I need? A: WD-914-A16V09-Dual-Audio-On.
Q: Single cam, audio off, journey snapshot on. What config? A: WD-919-A16V09-Single-Audio-Off-snapshot.
Q: Single cam, audio off, journey snapshot off. What config? A: WD-916-A16V09-Single-Audio-Off.
Q: Dual camera, audio off, journey snapshot on, DMS on, in cab warning on. What config? A: WD-929-A16V09-Dual-Audio-Off-DMS-WARN-snap.
Q: Dual camera, audio off, journey snapshot off, DMS on, in cab warning on. What config? A: Not available — this combination has no valid configuration.
Q: Dual camera, audio on, journey snapshot off, DMS on, in cab warning off. What config? A: WD-923-A16V09-Dual-Audio-On-DMS-NOWARN.
Q: Do I need to answer the In Cab Warning question for a single camera setup? A: No. In Cab Warning and DMS only apply to Dual camera configurations, and In Cab Warning only applies when DMS is On.
Q: What if DMS is off on a dual camera setup — do I still need to answer In Cab Warning? A: No. In Cab Warning only applies when DMS is On. If DMS is Off, the configuration is determined by Camera Count, Audio, and Journey Snapshot alone.
